VESTAS V-80 wind turbine Print
by solarmikeThis is a 1.8 Million Watt wind turbine
V80-1.8 MW
The cornerstone of our 2 MW class is the well-proven V80-2.0 MW wind turbine which is the closest we come to a mainstream turbine for medium and high wind sites. This competitive pitch regulated model with OptiSpeed® is available in many different tower heights, from 60-100 metres. The V80 is also available in a 1.8 MW OptiSlip® version for the US market.
Technical specifications
Rotor
Diameter: 80 m
Swept area: 5,027 m2
Speed revolution: 15.5/16.8 rpm
Number of blades: 3
Power regulation: Pitch/OptiSlip®
Air brake: Three separate pitch settings
Tower
Hub height (approx.): 60 - 67 - 78m
Operational data
Cut-in wind speed: 4 m/s
Nominal wind speed: 16 m/s
Stop wind speed: 25 m/s
Generator
Type: Asynchronous with OptiSlip®
Nominal output: 1.8 MW
Operational data: 60 Hz
690 V
1,800-1,980 rpm
Gearbox
Type: Planet/parallel gear
Control
Type: Microprocessor - based control of all turbine fuctions with the option of remote monitoring.
OptiSlip® output regulation and OptiTip® ptich regulation of the blades.
Weight
60 m 67 m 78 m
Nacelle: 138,915 lbs 138,915 lbs 138,915 lbs
Rotor: 77,175 lbs 77,175 lbs 77,175 lbs
www.vestas.com
